Specs - Martian Robots

The user input constructor

• verifies that user input corresponds to defined input format, e.g.
• 5 3
• 1 1 E
• RFRFRFRF
• 3 2 N
• FRRFLLFFRRFLL
• 0 3 W
• LLFFFLFLFL
• processes first line as grid coordinates (x, y) of maximum 50 each
• processes every following 2-line block as robot instructions
• whose first line sets position (x,y) and a direction (N, E, S, W)
• whose second line contains string of instruction letters (so far L, R, F but expendable)

The planet constructor

• lays out a 2-dimensional grid
• provides functionality to check if position is inside grid
• provides functionality to scent grid cell
• provides functionality to check grid cell value

The robot constructor

• puts a robot on grid cell with its direction (ignores robots with coordinates outside the current grid)
• provides functionality to turn left on same cell ('L')
• provides functionality to turn right on same cell ('R')
• provides functionality to move one cell forward ('F')
• that marks last grid cell with 'scent' if robot moves off grid
• that ignores any instruction that would move it from the grid when it stands on a 'scented' grid cell point

The program's output

• tells the position of each robot per line in the format like position input
• adds 'LOST' to the last position before robot moved off grid
• uses the same format as the programs input, eg.
• 1 1 E
• 3 3 N LOST
• 2 3 S

Martian_robots.js

// martian_robots.js

// define global object to save current planet and output
var global = {};

// UserInput constructor to check input and clean it up for further processing
function UserInput(input) {
  this.userInput = this.verify(input);
  this.roboInstructions = [];
}

// if correct commands are entered pull them out and ignore the rest; wrong input returns false
UserInput.prototype.verify = function (input){

  // input regex, if new instruction letter gets added to program modify [LRF] in regex and adjust Robot.prototype accordingly
  var pGridAndCommands = /(\d+\s+\d+\s*\n+)((\d+\s+\d+\s*[NESW]{1}\s*\n+[LRF]+\s*\n*)+)/i;

  var verify = input.match(pGridAndCommands);
  if (!verify) {
    return false;
  } else {
    return verify[0];
  }
};

// deconstruct verified input
UserInput.prototype.processInput = function (){
  var pSplitLines = /[\r?\n]+/;
  var pGridDefinition = /\d{1,2}\s+\d{1,2}/;
  var pSplitWhitespace = /\s+/;
  var pDirection = /[NESW]/;
  var pInstruction = /[RLF]+/;

  // create array of input and throw out empty elements
  var lines = splitLines(this.userInput).filter(Boolean);

  function splitLines(string) {
    return string.split(pSplitLines);
  }

  // first line is always grid definition and gets shifted from lines array
  this.gridCoordinates = lines.shift().match(pGridDefinition)[0].split(pSplitWhitespace);

  // iterate over raw robot instruction; two elements form one robot instruction
  for (var i = 0; i < lines.length; i+=2) {
    var rawCoordinates = lines[i];
    var rawInstruction = lines [i+1];
    var xy = rawCoordinates.match(pGridDefinition)[0].split(pSplitWhitespace);
    var direction = rawCoordinates.match(pDirection)[0];
    var instruction = rawInstruction.match(pInstruction)[0];
    this.newRoboCommand(xy[0],xy[1],direction,instruction);
  }
};

// build roboInstructions object and push it to instructions array
UserInput.prototype.newRoboCommand = function newRoboCommand (x,y,direction,instruction) {
  var command = {
    x: x,
    y: y,
    direction: direction,
    instruction: instruction
  };
  this.roboInstructions.push(command);
};

// set up Planet grid constructor
function Planet (gridCoordinates) {

  // add 1 to width and height so smallest possible grid has 4 cells when entered 0,0
  this.width = parseInt(gridCoordinates[0]) + 1;
  this.height = parseInt(gridCoordinates[1]) + 1;

  // create cells array to push scented cells information
  this.cells = new Array (this.height * this.width);
}

// check if cell is inside grid
Planet.prototype.isInside = function (point) {
  return point.x >= 0 && point.y >= 0 && point.x < this.width && point.y < this.height;
};

// scent cell value
Planet.prototype.scentAt = function (point) {
  this.cells[point.y * this.width + point.x] = "scent";
};

// check value of cell
Planet.prototype.valueAt = function (point) {
  return this.cells[point.y * this.width + point.x];
};


// Robot constructor to build single robots
function Robot (x, y, direction, instruction) {
  this.position = {
        x:parseInt(x),
        y:parseInt(y)
  };
  this.direction = direction;
  this.instruction = instruction;
  this.lost = false;
}

// execute instruction string
Robot.prototype.move = function () {

  // if initial robot position is not in grid it gets ignored
  if (global.mars.isInside(this.position)) {
    for (var i = 0; i < this.instruction.length; i++) {

      // take into account yet defined instruction - add more instructions here
      if (this.instruction.charAt(i) === 'L') {this.direction = (this.turnLeft(this.direction));}
      if (this.instruction.charAt(i) === 'R') {this.direction = (this.turnRight(this.direction));}
      if (this.instruction.charAt(i) === 'F') {
        this.moveForward();

        // break out of iterating when robot is lost
        if (this.lost === true) {break;}
      }
    }

    // push result of move operation to output array
    if (this.lost === true) {
      global.output.push(this.position.x + " " + this.position.y + " " + this.direction + " " + "LOST");
    } else {
      global.output.push(this.position.x + " " + this.position.y + " " + this.direction);
    }
  }
};

// turn direction 90 degrees left
Robot.prototype.turnLeft = function (direction) {
  var currentDir = ["N", "E", "S", "W"].indexOf(direction);
  if(currentDir === 0){currentDir = 4;}
  return ["N", "E", "S", "W"][currentDir - 1];
};

// turn direction 90 degrees right
Robot.prototype.turnRight = function (direction) {
  var currentDir = ["N", "E", "S", "W"].indexOf(direction);
  if(currentDir === 3){currentDir = -1;}
  return ["N", "E", "S", "W"][currentDir + 1];
};

// move robot one cell in current direction
Robot.prototype.moveForward = function () {
  var oldPosition = {x: this.position.x, y: this.position.y};

  if (this.direction === "N") {this.position.y ++;}
  if (this.direction === "E") {this.position.x ++;}
  if (this.direction === "S") {this.position.y --;}
  if (this.direction === "W") {this.position.x --;}

  // check if new position is outside grid
  if (global.mars.isInside(this.position) === false) {

    // set position to before moving off grid
    this.position = oldPosition;

    // if this.position not scented mark robot as lost and scent position
    if (global.mars.valueAt(this.position) !== "scent") {
      global.mars.scentAt(this.position);
      this.lost = true;
    }
  }
};


// initiate DOM with button functions
function initiate () {

  // iterate over robot instructions
  function startRobots (commands) {
    global.output = [];
    for (var i = 0; i < commands.length; i++) {
      var current = commands[i];
      var robot = new Robot (current.x, current.y, current.direction, current.instruction);
      robot.move();
    }
  }

  var goClick = document.getElementById("go");
  goClick.onclick = function run(){
    var input = document.getElementById("instructions").value;
    var command = new UserInput(input);

    if (!command.userInput) {
      alert("This input is invalid! Did you enter it in the correct format?");
    } else {
      command.processInput();
      if (command.gridCoordinates[0]>50 || command.gridCoordinates[1]>50) {
        alert("Maximum grid value is 50");
      }

      // only lay out grid and process robot instructions if input is correct
      else {

        // lay out current grid
        global.mars = new Planet (command.gridCoordinates);

        // process all user instructions
        startRobots(command.roboInstructions);

        // push result to dom element
        document.getElementById("output").value = global.output.join("\n");
      }
    }
  };

  // reset the global object
  var clearClick = document.getElementById("clear");
  clearClick.onclick = function (){
    document.getElementById("instructions").value = "";
    document.getElementById("output").value = "";
    global = {};
  };
}

// automatically run initate when script loads
initiate();
